China Century Marine Equipment Co., Ltd We Supply polyamide, polyester, polyethylene, polypropylene, macromolecular polyethylene ropes.
9 Years
| Ask Lasest Price | |
| Brand Name : | CCME |
| Certification : | ABS/CCS/BV/RS/DNV/LR/NK/GL/RINA/KR |
| Model Number : | CCME |
| Price : | negotiable |
| Delivery Time : | per the quantity |
| Payment Terms : | T/T L/C |
| Supply Ability : | 1000 rolls per month |
3.Melting point:165°c.
3.UV stabilized.
Advantage:
1.Designed for high tension work loading,can be used as mooring ropes.
2.The breaking strength is 30% stronger than normal pp.
3.The durability of this rope does not decrease as thestrength of the load is in creased.
4.The specific gravity is 0.91,can float in water.
5.Superior abrasion resistance,high intensity and easy handling.
6.It will become elongated when necessary to absorb shocks.
7.Introduced imported equipments with advanced techniques to produce.
Application:The rope widly is used in ocean fishing,blue water culture,industry,marine,mooring.
Technical specifications :
(SIZE) | (kg/220mweight) | TonsBreaking Strength | ||
MmDia | InchCir | 8-Strand | 12-Strand | |
32 | 4 | 102 | 16.8 | 17.4 |
36 | 4-1/2 | 129 | 21.0 | 21.8 |
38 | 4-3/4 | 145 | 22.0 | 23.0 |
40 | 5 | 158 | 26.2 | 27.5 |
44 | 5-1/2 | 194 | 31.2 | 32.5 |
48 | 6 | 229 | 36.3 | 38.0 |
52 | 6-1/2 | 268 | 43.0 | 45.0 |
56 | 7 | 312 | 48.1 | 50.5 |
60 | 7-1/2 | 359 | 55.5 | 58.3 |
64 | 8 | 407 | 62.1 | 65.2 |
72 | 9 | 515 | 77.7 | 81.6 |
80 | 10 | 638 | 95.6 | 100 |
88 | 11 | 772 | 116 | 122 |
96 | 12 | 916 | 136 | 142 |
104 | 13 | 1070 | 158 | 165 |
112 | 14 | 1250 | 184 | 192 |
120 | 15 | 1430 | 205 | 213 |
|
|
